Price From

N/A

Power

8.5kW at 7500 r/min

Max. Torque

12.0N·m/5500 r/min

Dry Weight (KG)

N/A

Tech Specs

  • Displacement (cc)

    171.7

    Type

    1-cylinder/4-stroke/2-valve

    Bore x Stroke (mm)

    ø61.5×57.8

    Power

    8.5kW at 7500 r/min

    Max. torque

    12.0N·m/5500 r/min

    Compression ratio

    9.75±0.2:1

    Fuel system

    Carburetor & EFI

    Valve train

    SOHC

    Ignition

    TCI

    Starter

    Electric & Kick

    Lubrication system

    Pressure splash lubrication

    Cooling system

    Forced-air-cooled

  • Gearbox

    Automatic CVT

    Final drive

    Belt

    Clutch type

    Automatic

  • Front wheel

    Alloy

    Front suspension

    Telescopic forks

    Front suspension travel (mm)

    75

    Front tyre

    110/70-13

    Rear wheel

    Alloy

    Rear suspension

    Dual shock-absorber

    Rear suspension travel (mm)

    50

    Rear tyre

    130/70-13

    Front brake

    Disc

    Front brakes diameter (mm)

    240

    Rear brake

    Disc

    Rear brakes diameter (mm)

    215

  • Seat height (mm)

    770

    Overall length (mm)

    1930

    Overall width (mm)

    755

    Overall height (mm)

    1130

    Ground clearance (mm)

    135

    Wheelbase (mm)

    1385

    Fuel capacity (L)

    9.5

    Top speed (km/h)

    95

    Max. load (kg)

    160

    Battery

    12V8Ah
