Precio desde

N/A

Potencia

9.5kW at 7500 r/min

Máximo. Torsión

13.9N·m/6000 r/min

Peso seco

156

Especificaciones técnicas

  • Displacement (cc)

    197

    Type

    1-cylinder/4-stroke/2-valve

    Bore x Stroke (mm)

    ø63.5x62.2

    Power

    9.5kW at 7500 r/min

    Max. torque

    13.9N·m/6000 r/min

    Compression ratio

    8.3:1

    Fuel system

    Carburetor

    Valve train

    OHV

    Ignition

    CDI

    Starter

    Electric & Kick

    Lubrication system

    Pressure splash lubrication

    Cooling system

    Air-cooled

  • Gearbox

    5-speed

    Final drive

    Chain

    Clutch type

    Wet multi-plate

  • Front wheel

    Alloy

    Front suspension

    Telescopic forks

    Front suspension travel (mm)

    120

    Front tyre

    90/90-17

    Rear wheel

    Alloy

    Rear suspension

    Dual shock-absorber

    Rear suspension travel (mm)

    53

    Rear tyre

    130/90-15

    Front brake

    Disc

    Front brakes diameter (mm)

    280

    Rear brake

    Disc

    Rear brakes diameter (mm)

    240

  • Curb weight (kg)

    156

    Seat height (mm)

    715

    Overall length (mm)

    2140

    Overall width (mm)

    800

    Overall height (mm)

    1050

    Ground clearance (mm)

    150

    Wheelbase (mm)

    1440

    Fuel capacity (L)

    11.8

    Top speed (km/h)

    100

    Max. load (kg)

    185

    Battery

    12V6Ah
