Price From

N/A

Power

14.0kW at 6500 r/min

Max. Torque

22.0N·m/6000 r/min

Dry Weight (KG)

147

Tech Specs

  • Displacement (cc)

    278.2

    Type

    1-cylinder/4-stroke/4-valve

    Bore x Stroke (mm)

    ø75×63

    Power

    14.0kW at 6500 r/min

    Max. torque

    22.0N·m/6000 r/min

    Compression ratio

    11:1

    Fuel system

    EFI

    Valve train

    SOHC

    Ignition

    TCI

    Starter

    Electric

    Lubrication system

    Pressure splash lubrication

    Cooling system

    Liquid-cooled

  • Gearbox

    Automatic CVT

    Final drive

    Belt

    Clutch type

    Automatic

  • Front wheel

    Alloy

    Front suspension

    Telescopic forks

    Front suspension travel (mm)

    85

    Front tyre

    110/70-13

    Rear wheel

    Alloy

    Rear suspension

    Dual shock-absorber

    Rear suspension travel (mm)

    60

    Rear tyre

    130/70-13

    Front brake

    Disc

    Front brakes diameter (mm)

    240

    Rear brake

    Disc

    Rear brakes diameter (mm)

    220

  • Curb weight (kg)

    147

    Seat height (mm)

    770

    Overall length (mm)

    1930

    Overall width (mm)

    800

    Overall height (mm)

    1130

    Wheelbase (mm)

    1390

    Fuel capacity (L)

    12

    Top speed (km/h)

    120

    Max. load (kg)

    150

    Battery

    12V10Ah
