Prezzo di Listino

N/A

Potenza

7.8kW at 9000 r/min

Coppia

8.9N·m/7500 r/min

Peso a secco (kg)

162

Specifiche tecniche

  • Displacement (cc)

    124

    Type

    1-cylinder/4-stroke/2-valve

    Bore x Stroke (mm)

    ø56.5×49.5

    Power

    7.8kW at 9000 r/min

    Max. torque

    8.9N·m/7500 r/min

    Compression ratio

    9:1

    Fuel system

    EFI

    Valve train

    OHV

    Ignition

    TCI

    Starter

    Electric & Kick

    Lubrication system

    Pressure splash lubrication

    Cooling system

    Air-cooled

  • Gearbox

    5-speed

    Final drive

    Chain

    Clutch type

    Wet multi-plate

  • Front wheel

    Alloy

    Front suspension

    Telescopic forks

    Front suspension travel (mm)

    110

    Front tyre

    110/90-16

    Rear wheel

    Alloy

    Rear suspension

    Dual shock-absorber, 5-stage adjustable preload

    Rear suspension travel (mm)

    73.2

    Rear tyre

    130/90-15

    Front brake

    Disc with CBS

    Front brakes diameter (mm)

    276

    Rear brake

    Disc with CBS

    Rear brakes diameter (mm)

    240

  • Curb weight (kg)

    162

    Seat height (mm)

    730

    Overall length (mm)

    2230

    Overall width (mm)

    850

    Overall height (mm)

    1150

    Ground clearance (mm)

    120

    Wheelbase (mm)

    1440

    Fuel capacity (L)

    12.5

    Top speed (km/h)

    90

    Max. load (kg)

    190

    Battery

    12V6Ah
