Price From

N/A

Power

7.2kW at 8000 r/min

Max. Torque

9.6N·m/6500 r/min

Dry Weight (KG)

135

Tech Specs

  • Displacement (cc)

    124.6

    Type

    1-cylinder/4-stroke/4-valve

    Bore x Stroke (mm)

    ø52.4x57.8

    Power

    7.2kW at 8000 r/min

    Max. torque

    9.6N·m/6500 r/min

    Compression ratio

    10.3:1

    Fuel system

    EFI

    Valve train

    SOHC

    Ignition

    TCI

    Starter

    Electric

    Lubrication system

    Pressure splash lubrication

    Cooling system

    Forced-air-cooled

  • Gearbox

    Automatic CVT

    Final drive

    V-Belt

    Clutch type

    Automatic

  • Front wheel

    Alloy

    Front suspension

    Telescopic forks

    Front suspension travel (mm)

    50

    Front tyre

    Timsun 120/70-12

    Rear wheel

    Alloy

    Rear suspension

    Dual shock-absorber, 5-stage adjustable preload

    Rear suspension travel (mm)

    50

    Rear tyre

    Timsun 120/70-12

    Front brake

    Disc with CBS

    Front brakes diameter (mm)

    220

    Rear brake

    Disc with CBS

    Rear brakes diameter (mm)

    215

  • Curb weight (kg)

    135

    Seat height (mm)

    780

    Overall length (mm)

    1980

    Overall width (mm)

    710

    Overall height (mm)

    1160

    Ground clearance (mm)

    140

    Wheelbase (mm)

    1380

    Fuel capacity (L)

    10

    Top speed (km/h)

    85

    Max. load (kg)

    160

    Battery

    12V8Ah
