Preț de la

N/A

Putere

9.4kW at 9500 r/min

Max. Cuplu

10.0N·m/8500 r/min

Greutate uscată (KG)

147

Specificații tehnice

  • Displacement (cc)

    125

    Type

    1-cylinder/4-stroke/4-valve

    Bore x Stroke (mm)

    ø54×54.5

    Power

    9.4kW at 9500 r/min

    Max. torque

    10.0N·m/8500 r/min

    Compression ratio

    11.6:1

    Fuel system

    EFI

    Valve train

    SOHC

    Ignition

    TCI

    Starter

    Electric

    Lubrication system

    Pressure splash lubrication

    Cooling system

    Liquid-cooled

  • Gearbox

    6-speed

    Transmission type

    Chain

    Clutch type

    Wet multi-plate

  • Front wheel

    Alloy

    Front suspension

    Upside-down telescopic forks

    Front suspension travel (mm)

    110.5

    Front tyre

    CST 100/80-17

    Rear wheel

    Alloy

    Rear suspension

    Pro-link Mono shock-absorber

    Rear suspension travel (mm)

    44

    Rear tyre

    CST 130/70-17

    Front brake

    Disc with ABS

    Front brakes diameter (mm)

    260

    Rear brake

    Disc with ABS

    Rear brakes diameter (mm)

    220

  • Curb weight (kg)

    147

    Seat height (mm)

    810

    Overall length (mm)

    2030

    Overall width (mm)

    780

    Overall height (mm)

    1070

    Ground clearance (mm)

    170

    Wheelbase (mm)

    1345

    Fuel capacity (L)

    10

    Top speed (km/h)

    99

    Max. load (kg)

    185

    Battery

    12V6Ah
