Τιμή

N/A

Μέγιστη ισχύς

5.3kW/8000

Μέγιστη Ροπή

8.0N·m/4500 r/min

Βάρος χωρίς υγρά (KG)

95

Τεχνικές Προδιαγραφές

  • Displacement (cc)

    107

    Type

    1-cylinder/4-stroke/2-valve

    Bore x Stroke (mm)

    52.4x49.5

    Power/rpm

    5.3kW/8000

    Max. torque

    8.0N·m/4500 r/min

    Compression ratio

    9.1:1

    Fuel system

    Carburetor

    Valve train

    OHV

    Ignition

    CDI

    Starter

    Electric & Kick

    Lubrication system

    Pressure splash lubrication

    Cooling system

    Air-cooled

  • Gearbox

    5-speed

    Transmission type

    Chain

    Clutch type

    Wet multi-plate

  • Front wheel

    Alloy

    Front suspension

    Telescopic forks

    Front suspension travel (mm)

    90

    Front tyre

    2.50-17

    Rear wheel

    Alloy

    Rear suspension

    Dual shock-absorber

    Rear suspension travel (mm)

    62

    Rear tyre

    2.75-17

    Front brake

    Disc

    Front brakes diameter (mm)

    220

    Rear brake

    Drum

    Rear brakes diameter (mm)

    110

  • Curb weight (kg)

    95

    Seat height (mm)

    770

    Overall length (mm)

    1940

    Overall width (mm)

    670

    Overall height (mm)

    1070

    Ground clearance (mm)

    140

    Wheelbase (mm)

    1240

    Fuel capacity (L)

    3

    Top speed (km/h)

    83

    Max. load (kg)

    150

    Battery

    12V5Ah
